Benchi offers Side Tipper Trailer in stock and customized. All products are guaranteed for quality and quantity and fast delivery is ensured.
Tri Axle Side Tipper Trailer Application
The 3 Axle Side Tipper Trailer is commonly used to transport a variety of bulk materials, such as: for mining to transport minerals and earth materials; for construction to move building materials such as sand and gravel; and for agriculture to transport large quantities of soil, fertilizer or crops.
Before purchasing, you should fully understand your application scenario. If you’re not sure if the Side Tipper Trailer is right for your transportation business, be sure to contact us and we’ll be more than happy to help you choose the right semi-trailer.
InquireTri Axle Side Tipper Trailer Specifications
| 3 Axle Side Tipper Trailer Specifications | |
|---|---|
| Dimensions | Overall: 12500×2500×3230mm Body Inside: 12100×2500×1500mm Volume: 30-70 tons |
| Material | Floor: 6-8mm High strength steel Sidewall: 3-5mm High strength steel Beam: Domex 600 or equal steel “I” section double web Cylinder: 6 set bottom cylinder |
| Axles | Number: 3/4/6 Axles, tandem axle Specification: 3 axle 13T/16T, FUWA / BPW Brand |
| Tires | Options: 12.00R20 / 13R22.5 or customized Additional Sizes: 8.25R20/10.00R20/11.00R20/12R22.5 |
| Suspension | Types: Mechanical/Air/Bogie optional Specific: Mechanical suspension Leg: JOST exchangeable type |
| Brake System | Type: Dual air brake system Components: WABCO chamber and valve |
| Electrical System | Specification: 12v/24v, 7 line cable Lighting: LED light (especially intended for overseas markets) |
| Lifting System | Lifting cylinder 5×130 bore, a shift cylinder |
| Rims | 8.0-20 or 9.00-20 |
| Spring Leaf | 90(W)mmx13(Thickness)mmx10 layers |
| Kingpin | JOST brand 2.0 or 3.5inch (bolted or welded type) |
| Landing Gear | JOST brand |
| Chassis | Height: 480mm Plates: Upper plate: 14mm, Middle plate: 8mm, Lower plate: 16mm Material: T700 steel ABS: Optional Valve: WABCO valve Voltage: 24V |
| Accessories | One standard tool box One rocker handle One Shaft wrench |
| Painting | Process: Sandblasted, anti-rust chassis surface Coating: 1 layer of anticorrosive primer and 2 layers of topcoats |
Product Advantages
- The cargo box is made of high-strength Hardox 450 or equivalent wear-resistant material;
- The crossbeam uses T700 steel, which is lighter in self-weight and more fuel-efficient;
- The whole vehicle is made of solid materials, with long service life and not easy to fail;
- The bottom plate of the cargo box is thickened and not easy to be deformed.
Tri Axle Side Tipper Trailer Detail
Famous Brand Hydraulic Cylinder
Thickened Base Plate
